| Black level | - Black level file enabled / disabled
- Black Level file selected (if available)
- Basic black level enabled / disabled
- Black level settings (top / bottom / left / right)
- RGB gain values (Red, Green and Blue values)
|
| Blend | - Blend mask enabled / disabled
- All Masks (top / bottom / left / right) and heights (top / bottom / left / right)
- Blend files enabled / disabled (if available)
- Blend file selected (if available)
|
| Cooling[2] | Selected Cooling mode |
| Display (3D settings) | - 3D Display mode used
- Swap eyes on / off
- Swap frame pair on / off
- Dark time and sync delay values
|
| HDR | - Screen luminance (unit and value)
- HDR Boost value
- DynaBlack mode
|
| Illumination | - Illumination power of light source
- Light sensor enabled / disabled
- Light sensor set point
|
| Image | - Contrast
- Brightness
- Saturation
- Sharpness
- Gamma
- Used gamma type
- Digital zoom (width / height / factor + enabled/disabled)
- Digital shift (x / y + enabled / disabled)
- Output resolution
|
| Installation | - Lens parameters (lens zoom, focus, shift and iris (if available))[3]
- Orientation (mounting & projection)
- Scaling mode
- Position of motorized frame (if used).
- Shutter status (open or closed).
|
| Operational mode[4] | Selected Operational mode |
| Realcolor™ | - Brilliant Color mode (if available)
- P7 desired values
- P7 measured values
|
| Source | Active source selection & EDID |
| Warp | - Warp status enabled / disabled
- Screen size
- Warp file selected (if available)
- Transport delay
Note: Bow and 4 corners warp cannot be saved. |
