9.9 T-Bar

EC-40 Overview
Image 9–8 EC-40 T-bar
1
T-bar
R
Right side of the controller
Description

A traditional manual transition T-bar is included in the consoles. It is placed on the far right side of the console for convenience.

The T-bar will transition from 0 to 100% of the transition for Destinations and will cut Auxiliary at 100%.

In the event of a unknown state a up or down motion of the T-bar will re-align the T-bar to 0%. If the unknown state was between 0 and 100% the T-bar will continue and push the transition thru to 100%.
