13.11 VPU Card(s)

Flow chart
Image 13–30
Overview
Image 13–31 VPU cards
1
Chassis
2
VPU cards
Concerned parts
R9009369VPU Card
Necessary tools

1 x Phillips Screwdriver #2 (optional).

How to remove a VPU Card

  1. Locate the VPU you need to replace.

    Note: There are 9 VPU slots. The first slot on the left is slot 15 and the last slot on the most right position is 23.
  2. Loosen and unscrew the thumbscrew that is holding VPU card to the chassis.

  3. Pull the VPU out of its slot.

    Image 13–32 VPU card removal
How to install a VPU Card

To install a VPU Card follow the same procedure in the reverse order.
