Location

IMS main sidebar > Group view > Network configuration > Manual

Layout

How to set group network settings in manual mode

1. Select the group by clicking on the group name from the Projector groups sidebar.

2. Enter in the IP address, Hostname, Subnet mask, Default gateway, Name servers.



   Note: Name servers are IP addresses of servers that handle name resolution on the network. Up to two name servers can be entered.

3. Click Send.

   The Send IP Configuration window will be prompted.



4. Click Apply.

   The request is sent to the devices, and when it succeeds, it refreshes the network settings.
