    Coronis Uniti (MDMC‑12133)

    12MP diagnostic display system for PACS and breast imaging

    Coronis Uniti (MDMC‑12133)

    12MP diagnostic display system for PACS and breast imaging

    • PACS and breast imaging on one display
    • In grayscale and color (featuring unique color calibration!)
    • With touchpad for fast control
    Get your quote Where to buy
    1. Download specsheet
    2. Download brochure
    3. Get product support

    K9301680A

    Coronis Uniti - MDMC-12133

    Coronis Uniti. Enjoy your reading room

    With Coronis Uniti, you’re working with the biggest and most equipped display system that exists for general radiology and breast imaging. Experience the power of a feature-rich design and a strong engine that renders rich content, while enabling fast-paced, dynamic, and 3D medical imaging.

    Please consult your Barco representative or distributor in your country or territory to confirm availability. A reference to any product or service on this site does not imply that such product is or will be available in your location.



    Perfect your workflow

    Coronis Uniti is designed to allow images of a wide range of modalities: from x-rays and ultrasounds to 3D mammography. It’s the solution that replaces all display configurations, so say bye to multi-head setups or other workstations to view additional exams.

    Specifications

    Download spec sheet
    General specifications
    Screen technology
    IPS
    Active screen size (diagonal)
    853.44 mm (33.6")
    Active screen size (H x V)
    708.1 x 472.1 mm (27.8 x 18.6")
    Aspect ratio (H:V)
    3:2
    Resolution
    12MP (4200 x 2800 pixels)
    Pixel pitch
    0.1686 mm
    Color imaging
    Yes
    Gray imaging
    Yes
    Bit depth
    30 bit
    Viewing angle (H, V)
    178°
    Optical glass
    Yes
    Uniformity correction
    PPU
    SteadyColor Calibration
    Yes
    I-Luminate
    Yes
    Ambient Light Compensation (ALC)
    Yes, reading room selection
    Ambient light sensor
    Yes
    Backlight Output Stabilization (BLOS)
    Yes
    Front sensor
    Yes, I-Guard
    Maximum luminance
    2100 cd/m² (PPU on)
    DICOM calibrated luminance
    1000 cd/m²
    Contrast ratio (panel typical)
    1200:1 (PPU on)
    Response time ((Tr + Tf)/2) (typical)
    16.5 ms
    Housing color
    RAL 9004 / RAL 9003
    Video input signals
    DisplayPort 1.2
    USB ports
    1x USB 2.0 upstream (endpoint)
    3x USB 2.0 downstream
    Power rating
    24 VDC, 16.25 A; 5 VDC, 0.1 A
    Power requirements
    This device shall only be powered by the medical approved power supply of Efore (Roal Electronics), type RHPS390. Ratings marked on the medical approved power supply:
    • Input rating: 100-240 VAC, 5.5 A, 50/60 Hz
    • Output rating: 24 VDC, 16.25 A; 5 VDC, 0.1 A
    Power consumption
    190 W (nominal)
    < 0.5 W (hibernate)
    Dimensions with stand (W x H x D)
    795 x 610 x 300 mm (lowest position)
    Dimensions w/o stand (W x H x D)
    795 x 572 x 131 mm
    Dimensions packaged (W x H x D)
    960 x 715 x 395 mm
    Net weight with stand
    33 kg
    Net weight w/o stand
    23 kg
    Net weight packaged
    42 kg
    Tilt
    -5° / +30°
    Swivel
    -23° / +23°
    Pivot
    N/A
    Height adjustment range
    95 mm
    Mounting standard
    VESA (200 x 100 mm & 100 x 100 mm)
    Screen protection
    Protective, anti-reflective optical glass
    Recommended modalities
    All digital images, including digital mammography and breast tomosynthesis
    Certifications
    CE0123 (Medical Device)
    FDA 510(K) K151505 for General Radiology, Digital Mammography and Breast Tomosynthesis, Breast MRI, Breast US, CT, and Ultrasound including Vascular and Gynecological US
    CCC (China), KC (Korea), Inmetro (Brazil), BIS (India), NOM (Mexico), EAC (Russia, Kazakhstan, Belarus, Armenia and Kyrgyzstan)

    Safety specific:
    IEC 60950-1:2005 + A1:2009
    EN 60950-1:2006 + A1:2010 + A11:2009 + A12:2011 + A2:2013
    IEC 60601-1:2005 + A1:2012
    EN 60601-1:2006 + A1:2013 + A12:2014
    ANSI/AAMI ES 60601-1:2005 + R1:2012
    CAN/CSA C22.2 No. 60601-1:14

    EMI specific:
    IEC 60601-1-2:2014 (ed4)
    EN 60601-1-2:2015 (ed4)
    FCC part 15 Class B
    ICES-001 Level B
    VCCI (Japan)

    Environmental:
    China Energy Label, EU RoHS, China RoHS, REACH, Canada Health, WEEE, Packaging Directive
    Supplied accessories
    User Guide
    Quick Installation Sheet
    System Sheet
    Video cables
    Main cables
    USB 2.0 cable
    External power supply
    Film clip
    Barco Touchpad
    Optional accessories
    None
    QA software
    QAWeb
    Warranty
    5 years, including 40000 hours backlight warranty
    Operating temperature
    0°C to +35°C (+20°C to +30°C within spec)
    Storage temperature
    -20°C to +60°C
    Operating humidity
    20% - 85% (non-condensing)
    Storage humidity
    20% - 85% (non-condensing)
    Operating pressure
    70 kPa minimum
    Storage pressure
    50 to 106 kPa
