    G62‑W14

    13,600 lumens, WUXGA, DLP laser phosphor projector

    G62‑W14

    13,600 lumens, WUXGA, DLP laser phosphor projector

    • Great image quality
    • Optimal integration capabilities
    • 4K compatible and 3D-ready
    • Guaranteed service and support

    Get your quote Where to buy
    1. Download specsheet
    2. Get product support

    R9010372

    G62-W14 B

    The G62-W14 expand the single-chip offering with a quality WUXGA projector of 13,600 lumens. It opens up the possibilities to a wider range of applications while still relying on the valued Barco service and support.

    The laser phosphor light source ensures great image quality on the one hand, but also lower maintenance compared to most lamp-based projectors on the market. Thanks to Barco's Projector Toolset software, installing and managing your projector(s) can be done from the comfort of your own computer.

    The G62 models enable HDMI 2.0 input capabilities and higher bandwidth than its predecessors, which makes them 4K compatible and 3D capable to visualize your high-quality content at its best.

    The projectors are available in black and fully white chassis, allowing you to choose the perfect fit for your specific environment. Their uniform compact size, the compatibility with other Barco products and the wide lens shift range enlarge the projectors flexibility.

    Specifications

    Download spec sheet
    General specifications
    Projector type
    Single chip DLP laser phosphor projector
    Resolution
    1,920 x 1,200 (WUXGA)
    Brightness
    11,500 ANSI lumens
    12,800 center lumens
    13,600 ISO lumens
    Contrast ratio
    1,200:1 sequential; 6,000:1 dynamic; Extreme black: 750,000:1
    Brightness uniformity
    90%
    Aspect ratio
    16:10
    Lens type
    G-lenses - 0.36:1 / 0.37-0.4:1 / 0.65-0.75:1 / 0.75-0.95:1 / 0.95-1.22:1 / 1.22-1.52:1 / 1.52-2.92:1 / 2.90-5.50:1
    Optical lens shift
    Vertical up to 100%, depending on lens
    Horizontal up to 30%, depending on lens
    Motorized zoom and focus
    Motorized lens shift
    Color correction
    Yes
    CLO (constant light output)
    Yes
    Light source
    Laser phosphor
    Light source lifetime
    Up to 20,000hrs
    Sealed DLP™ core
    Yes
    Orientation
    360° rotation, no restrictions
    3D
    Active stereoscopic 3D
    Image processing
    Embedded warp & blend possible via Projector Toolset
    Inputs
    2x HDMI In (version 2.0) (with locking screw) / 1x DVI-D (only support digital signal) / 1x HDBaseT / 1x 3D SYNC In / 1x 3G-SDI
    Input resolutions
    Up to 4K UHD @60Hz
    Refresh rates: 24Hz to 60Hz for WUXGA and 4KUHD (4096 x 2160 / 3860 x 2160)
    4K input signals will be scaled to the projector’s output resolution
    Software tools
    Projector Toolset
    Control
    IR, RS232, RJ45, 3.5mm phone jack for wired remote
    Network connection
    10/100 Ethernet, RJ45
    Power requirements
    100-240V / 50-60Hz
    Power consumption
    1020W nominal, 1200W maximum
    BTU per hour
    4,002 BTU/h nominal; 4159 BTU/h maximum
    Standby power
    less than 0.5W
    Noise level (typical at 25°C/77°F)
    37dB(A) - 42dB(A) depending on the used mode
    Operating temperature
    0 ~ 40 °C (sea level)
    Storage temperature
    -10 ~ 60 °C
    Operating humidity
    10 - 85% RH, non-condensing
    Storage humidity
    5 - 90% RH, non-condensing
    Dimensions (WxLxH)
    without feet: 484 x 529 x 195 mm / 19.1 x 20.8 x 7.7 inch
    with feet: 484 x 529 x 206 mm / 19.1 x 20.8 x 8.1 inch
    Weight
    without lens: 22.7 kg / 50.1 lbs
    Standard accessories
    Power cord, wireless remote control
    Certifications
    CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI
    Warranty
    Limited 3 years parts and labor
