    Eonis 21" (MDRC-2321)
    Get your quote

    Eonis 21" (MDRC‑2321)

    21" clinical display for hospital-wide viewing of clinical data and images

    Eonis 21" (MDRC‑2321)

    21" clinical display for hospital-wide viewing of clinical data and images

    • 21" display for reviewing clinical images
    • With front sensor for consistent images
    • With remote QA management tools
    • Different versions available
    Get your quote Where to buy
    1. Download specsheet
    2. Get product support

    K9350053

    MDRC-2321 - Option SNIB

    K9350054

    MDRC-2321 - Option STIB

    This 21” Eonis display has been built with healthcare specialists in mind. It combines consistent, high image quality and an attractive, versatile design with networked quality assurance.

    High image quality

    The high-quality Eonis display presents sharp, bright images with high contrast and a wide viewing angle. Eonis uses the latest in advancements in LED backlight technology, ensuring a higher brightness that can be maintained over a longer period of time.

    The display’s unique front consistency sensor ensures fast power-up and continuous luminance stability. The image consistency makes collaboration between specialists easier. They can discuss images with colleagues at multiple locations, knowing that everyone is seeing identical images.

    Centralized quality assurance

    Eonis comes complete with Barco’s cloud-based QAWeb Enterprise software, an online service for automated calibration, Quality Assurance and asset management. Praised in hospitals around the world, QAWeb Enterprise allows healthcare IT and PACS administrators to centrally and remotely manage image quality across the healthcare organization, at the click of a button.

    Smart design, fit for purpose

    Barco’s Eonis display is safe to use in a clinical environment. The multiple mounting options and connections add to the smart design. The display is as high in brightness as it is low in power consumption. The lightweight form factor and packaging help reduce the environmental footprint of this product.

    Models

    • MDRC-2321 (Option SNIB): standard brightness, touchscreen, internal power supply, black
    • MDRC-2321 (Option STIB): standard brightness, touchscreen, internal power supply, black



    Please consult your Barco representative or distributor in your country or territory to confirm availability. A reference to any product or service on this site does not imply that such product is or will be available in your location.

    Specifications

    Download spec sheet
    General specifications
    Screen technology
    LCD
    Active screen size (diagonal)
    541.0 mm (21.3")
    Active screen size (H x V)
    432.0 mm x 324.0 mm (17.0 x 12.8")
    Aspect ratio (H:V)
    4:3
    Resolution
    2MP (1600 x 1200 pixels)
    Pixel pitch
    0.270 mm
    Color imaging
    Yes
    Gray imaging
    Yes
    Bit depth
    30 bit
    Viewing angle (H, V)
    178°
    Ambient light presets
    Yes, reading room selection
    Front sensor
    Yes, Front Consistency Sensor
    Maximum luminance
    Standard brightness versions (MDRC-2321 (option Sxxx)): 500 cd/m²
    High brightness versions (MDRC-2321 (option Hxxx)): 1000 cd/m²
    DICOM calibrated luminance
    Standard brightness versions (MDRC-2321 (option Sxxx)): 250 cd/m²
    High brightness versions (MDRC-2321 (option Hxxx)): 400 cd/m²
    Contrast ratio (panel typical)
    1800:1
    Response time ((Tr + Tf)/2) (typical)
    8 ms
    Housing color
    RAL 9004
    Video input signals
    1 x DP, 1 x DVI-I
    USB ports
    1x USB 2.0 upstream (endpoint)
    2x USB 2.0 downstream
    Power rating
    100-240 VAC, 50/60 Hz, 0.9-0.5 A
    Power consumption
    Standard brightness versions (MDRC-2321 option Sxxx): 20 W
    High brightness versions (MDRC-2321 option Hxxx): 25 W
    < 0.5 W (hibernate)
    < 0.5 W (standby)
    Dimensions with stand (W x H x D)
    Portrait: 374.5 x 506.6~583.3 x 201.3 mm
    Landscape: 477.0 x 411.5~529.6 x 201.3 mm
    Dimensions w/o stand (W x H x D)
    Portrait: 477.0 x 374.5 x 70.4 mm
    Landscape: 374.5 x 477.0 x 70.4 mm
    Dimensions packaged (W x H x D)
    660 x 513 x 230 mm
    Net weight with stand
    MDRC-2321 (option SNIB and HNIB): 5.8 kg
    MDRC-2321 (option STIB and HTIB): 6.8 kg
    Net weight w/o stand
    MDRC-2321 (option SNIB and HNIB): 3.6 kg
    MDRC-2321 (option STIB and HTIB): 4.6 kg
    Net weight packaged
    MDRC-2321 (option SNIB and HNIB): 8.4 kg (without optional accessories)
    MDRC-2321 (option STIB and HTIB): 9.4 kg (without optional accessories)
    Tilt
    -5° to +22°
    Pivot
    0° to 90°
    Height adjustment range
    110 mm
    Mounting standard
    VESA (100 mm)
    Screen protection
    MDRC-2321 (option STIB and HTIB): PCAP touchscreen
    MDRC-2321 (option SNIB and HNIB): None
    Recommended modalities
    All digital images, except digital mammography.
    Certifications
    FDA class I, 510(k) exempt
    CE (Medical Device Class I)
    CCC (China), KC (Korea), BIS (India)

    Safety specific:
    IEC 60950-1:2005 + A1:2009 +A2:2013
    EN 60950-1:2006 + A1:2010 + A11:2009 + A12:2011 + A2:2013
    IEC 60601-1:2005 + CORR. 1:2006 + CORR. 2:2007 + AM1:12
    EN 60601-1:2006 + A1:2013 + A12:2014
    ANSI/AAMI ES 60601-1:2005 + R1:2012
    CAN/CSA C22.2 No. 60601-1:2014
    EMI specific:
    IEC 60601-1-2: 2014 (ed4)
    EN 60601-1-2:2015 (ed4)
    FCC part 15 Class B
    ICES-003 Level B
    VCCI (Japan)
    Environmental:
    China Energy Label, EU RoHS, China RoHS, REACH, Canada Health, WEEE, Packaging Directive
    Supplied accessories
    1x DisplayPort video cable
    1x USB cable
    1x printed User Guide (in English, other languages can be found on the documentation disc)
    1x documentation disc
    1x system sheet
    Mains cables
    Optional accessories
    None
    QA software
    QAWeb
    Warranty
    3 years
    Operating temperature
    0 °C to 40 °C (15 °C to 35 °C within specs)
    Storage temperature
    -20 °C to 60 °C
    Operating humidity
    8% to 80% (non-condensing)
    Storage humidity
    5% to 90% (non-condensing)
    Operating pressure
    70 kPa minimum
    Storage pressure
    50 to 106 kPa
