• Event Master 工具组 Robust 版本 — Mac 和 PC 上的用户页面相同
  • 用于独立使用的板载处理
  • 完全控制 Event Master 系列处理器
  • 同一网络上同时连接多个控制器、GUI 接口和处理器

EC-210 活动控制器(EC-200 的后继产品)通过升级处理、外部输入和第三个外部显示选项,为您的活动带来更快的编程。享受其同胞EC-50的易用性,采用基于语法的编程方法,加速Event Master的商标简化操作。其结果是,对于今天的大型活动来说,控制器得到了极大简化,功能更加强大。


EC-210 兼容 EX、S3-4K 和 E2 Event Master 处理器,是一款独立的专用控制器,可直接在 Event Master 工具组中打开。现在,您只需动动手指即可选择源、预设、层和目标。EC-210 配备轨迹球、专用编程和操作部分以及两个触摸屏显示器。可将源切换至程序,同时还能选择较大资源组,并以全新的方式执行层操作。额外的外部输入意味着,现在,当空间紧张时,您可以在同一控制界面上同时显示用户界面和外部视频。



*EC-210 是 EC-200 的升级版。它们提供相同的功能,但略有不同。请参阅规格部分了解详情。现有的 EC-200 可以升级到与 EC-210 相同的规格和功能。

•Controls multiple EventMaster Series systems, including E2, S3-4K, and EX.
•Additional HDMI™ output to increase workspace.
•HDMI™ input for external video sources.
•Auto-ranging mains input (90-250VAC)
•External pointing device and Keyboards supported over USB
•2 separate gigabit Ethernet network interface connections, one for Primary system control, and one for supplemental network (additional IP address range and mode)
20.41 kg (45 lbs)
•Robust version of Event Master Toolset - same user interface used on Mac and PC
•Onboard processing section that is purpose-built to run Event Master toolset, enabling stand-alone usage. EC-210 processing section has been upgraded; the EC-200 is upgradeable to the EC-210 processor. (Users will experience faster performance with most tasks)
•Full control over the Event Master Series processors
•Simultaneous connection of multiple controllers, GUI interfaces, and processors supported on same network. (Redundant backups of control)
•2 internal 15.6-inch wide screen full HD (1,920x1,080) touchscreens with multi touch interface
•1 external HDMI™ output supporting up to 2560x1080
•External input for the left side internal screen. External HDMI™ video signals up to HD resolution. (Typical sources are Multi-viewer or Aux output from Event Master)
•High-resolution T-Bar for manual transitions
•36 user-assignable instant selection buttons with customizable LCD labels and multiple pages of assignments. (3 buses assignable as presets, cues, sources, backgrounds, or user keys)
•Dedicated Background layer button and 8 dedicated Layer selection buttons with multi-page selection. (Change pages for destinations with 9 or more layers)
•Dedicated layer transition and function buttons.(Trans, Cut, Freeze, etc.)
•12 user-definable Destination buttons with multiple pages of assignments (easily supports all the destinations available in future releases)
•Dedicated buttons for transitioning all selected destinations, live switching, modifying program, etc.
•Play/Pause and Stop button for Cues
•5 rotary encoders with wheels for ergonomic pip control and rapid placement of resources
•12 LCD Contextual Display Buttons to support the Syntax Programmer
•Tri-Axis backlit trackball (based on function), with a very smooth rotary encoder for the third axis and 4 buttons for cursor and position control (future software release)
•Internal, board mounted M2 SSD
•5 USB ports for additional accessories such as mouse, keyboard, thumbdrive, etc.
•Script lights, feedback LEDs, and integrated work lights with user controlled dimming.
•Power button for soft shutdown and restart of the system
•Back up and restore of system via USB or WebUI.
•Integrated WebUI for software upgrades.
•Dust cover included
•Custom road case included
* Note: The EC-210 HDMI™ monitor connections do not support analog output. Digital displays or active digital to analog converters are required.
244.34 x 901.19 x 575.36 mm / 9.62 x 35.49 x 22.65 in
0-35° C / 32-95° F
