G62‑W14

13,600 lumens, WUXGA, DLP laser phosphor projector

G62‑W14

13,600 lumens, WUXGA, DLP laser phosphor projector

Great image quality
Optimal integration capabilities
4K compatible and 3D-ready
Guaranteed service and support

R9010372

G62-W14 B

R90103721

G62-W14 B - Chinese version

R90103722

G62-W14 B - US version

R9010373

G62-W14 W

R90103731

G62-W14 W - Chinese version

R90103732

G62-W14 W - US version

The G62-W14 expand the single-chip offering with a quality WUXGA projector of 13,600 lumens. It opens up the possibilities to a wider range of applications while still relying on the valued Barco service and support.

The laser phosphor light source ensures great image quality on the one hand, but also lower maintenance compared to most lamp-based projectors on the market. Thanks to Barco's Projector Toolset software, installing and managing your projector(s) can be done from the comfort of your own computer.

The G62 models enable HDMI 2.0 input capabilities and higher bandwidth than its predecessors, which makes them 4K compatible and 3D capable to visualize your high-quality content at its best.

The projectors are available in black and fully white chassis, allowing you to choose the perfect fit for your specific environment. Their uniform compact size, the compatibility with other Barco products and the wide lens shift range enlarge the projectors flexibility.

Specificaties

Download specificatieblad

General specifications

Type projector: Single chip DLP laser phosphor projector

Resolutie: 1,920 x 1,200 (WUXGA)

Helderheid: 11,500 ANSI lumens 12,800 center lumens 13,600 ISO lumens

Helderheidsuniformiteit: 90%

Contrastverhouding: 1,200:1 sequential; 6,000:1 dynamic; Extreme black: 750,000:1

Lichtbron: Laser phosphor

Levensduur lichtbron: Up to 20,000hrs

Beeldverhouding: 16:10

Oriëntatie: 360° rotation, no restrictions

Verzegelde DLP™-kern: Yes

Kleurcorrectie: Yes

CLU (constante lichtuitvoer): Yes

Beeldverwerking: Embedded warp & blend possible via Ptoolset

3D: Active stereoscopic 3D

Type lens: G-lenses - 0.36:1 / 0.37-0.4:1 / 0.65-0.75:1 / 0.75-0.95:1 / 0.95-1.22:1 / 1.22-1.53:1 / 1.52-2.92:1 / 2.90-5.50:1

Optische lensverschuiving: Vertical up to 100%, depending on lens
Horizontal up to 30%, depending on lens
Motorized zoom and focus
Motorized lens shift

Ingangen: 2x HDMI In (version 2.0) (with locking screw) / 1x DVI-D (only support digital signal) / 1x HDBaseT / 1x 3D SYNC In / 1x 3G-SDI

Invoerresoluties: Up to 4K UHD @60Hz
Refresh rates: 24Hz to 60Hz for WUXGA and 4KUHD (4096 x 2160 / 3840 x 2160)
4K input signals will be scaled to the projector’s output resolution

Softwaretools: Projector Toolset and Insight Management Suite (IMS)

Controle: IR, RS232, RJ45, 3.5mm phone jack for wired remote

Netwerkverbinding: 10/100 Ethernet, RJ45

Voedingsvereisten: 100-240V / 50-60Hz

Energieverbruik: 810W nominal, 970W maximum

Stroom in stand-by: less than 0.5W

BTU/uur: 2,747 BTU/h nominal; 2883 BTU/h maximum

Geluidsniveau (standaard bij 25°C/77°F): 35dB(A) - 39dB(A) depending on the used mode

Bedrijfstemperatuur: 0 ~ 40 °C (sea level)

Vochtigheid in bedrijf: 10 - 85% RH, non-condensing

Opslagtemperatuur: -10 ~ 60 °C

Vochtigheid bij opslag: 5 - 90% RH, non-condensing

Afmetingen (B x L x H): without feet: 484 x 529 x 195 mm / 19.1 x 20.8 x 7.7 inch
with feet: 484 x 529 x 206 mm / 19.1 x 20.8 x 8.1 inch

Gewicht: without lens: 22.7 kg / 50.1 lbs

Standaardaccessoires: Power cord, wireless remote control

Certificeringen: CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI

Garantie: Limited 3 years parts and labor
