MDPC-8127

MDPC‑8127

27" 8MP, ultra-high definition display, cleared for digital pathology

  • Visual richness and color confidence
  • Panning and zooming with minimal blurring
  • Stable image quality & automated calibration

Lijstprijs:

((excl. btw, invoerrechten en vracht))

Prijs niet beschikbaar

Handleidingen, stuurprogramma's en ondersteuning

Meet MDPC-8127, our ultra-high definition medical grade display designed exclusively for digital pathology. With regulatory clearances as an IVD device (Europe and FDA) for use in digital pathology including primary diagnosis, it’s the first display that you can confidently integrate into your digital pathology workflow with multiple whole slide imaging systems.* Work with superior imaging technology and analyze your histological samples confidently, with unprecedented visual richness.

*In the USA the MDPC-8127 can be used with WSI scanners and viewing software that have been validated for use with the display.
The device may be used for primary diagnosis in the following validated FDA-cleared WSI systems and digital pathology viewing software:

Barco’s MDPC-8127 510(k) clearance:

  • Philips Intellisite Pathology Solution with Philips Image Management System viewing software, cleared under K192259
  • Philips Intellisite Pathology Solution with Paige.AI Inc. FullFocus DX viewing software, cleared under K201005
  • Leica Aperio AT2 DX System with ImageScope DX viewing software, cleared under K190332
  • Leica Aperio AT2 DX scanner with Sectra Digital Pathology Module, cleared under K193054

FDA- Cleared WSI systems and Digital Pathology Viewing Software with MDPC-8127:

  • Hamamatsu NanoZoomer S360MD slide scanner system, cleared under K233027
  • Leica Aperio GT 450 DX scanner with Aperio WebViewer DX, cleared under K232202
  • Philips Intellisite Pathology Solution with JelloX MetaLite Dx Digital Pathology Software, cleared under K240303
  • Philips IntelliSite Pathology Solution with Philips Image Management System and Galen™ Second Read™ AI, cleared under K241232
  • Epredia E1000 Dx scanner with E1000 Dx IMS, cleared under K241717
  • Hamamatsu NanoZoomer S360MD scanner with Lumea Viewer+, cleared under K242244

MDPC-8127 Validation protocol:

  • Leica Aperio GT 450 DX scanner with Sectra Digital Pathology Module (3.3)
  • Roche Ventana DP200 scanner with Roche uPath Enterprise Software
  • Hamamatsu NanoZoomer S360MD Slide scanner with Proscia Concentriq® AP-Dx Digital Pathology software

A+ ecolabel for MDPC-8127

The MDPC-8127 has been subjected to Barco’s ecoscoring protocol and has received an A+ rating. Some key factors that contributed to this rating are:

  • High energy efficiency
  • Possibility to switch to standby mode when device is not in use
  • Use of halogen-free materials on all levels: cables, PCBs, plastics
  • Number of screws and screw types is reduced significantly to improve ease of disassembly
  • Unpainted large plastic parts

Ultrahoge definitie

Het 8 megapixel, ultrahoge definitiescherm is volledig uitgerust om u diagnostische duidelijkheid te bieden. Het heeft een hoge pixeldichtheid en kleur-per-pixel-uniformiteit, zodat dia-afbeeldingen extreem scherp en consistent worden weergegeven. Deze combinatie van technologieën biedt u een beter zichtbaar diagebied om mee te werken, op alle zoomniveaus, om details gemakkelijker te herkennen en te helpen bij een tijdige analyse.

Algemene specificaties
Schermtechnologie
IPS LCD with LED backlight
Actieve schermgrootte (diagonaal)
684 mm (27")
Actieve schermgrootte (H x V)
569 x 335 mm (22.4 x 13.2")
Beeldverhouding (H:V)
16:9
Resolutie
8MP (3840 x 2160 pixels @ 120 Hz)
Pixelpitch
0.155 mm
Kleurenbeeld
Yes
Grijsbeeld
Yes
Bitdiepte
10 bit (1.07 billion possible colors)
Kijkhoek (H, V)
178°
Uniformiteitscorrectie
PPU
SteadyColor
Yes, with QAWeb Enterprise
NTSC Kleurengamma
115% (typical)
Kleurengamma sRGB
132% (typical)
DCI-P3 Kleurengamma
105% (typical)
sRGB Delta E2000 (standaard)
< 1 (average)
< 3 (maximum)
Voorinstellingen voor omgevingslicht
Yes, reading room selection
Sensor voor omgevingslicht
Yes
Sensor aan de voorkant
Yes, I-Guard
Maximale luminance (afhankelijk van het paneel)
850 cd/m²
DICOM gekalibreerde luminantie
450 cd/m²
Contrastverhouding (afhankelijk van het paneel)
1000:1
Reactietijd ((Tr + Tf)/2) (normaal)
8 ms
Kleur behuizing
Black / White
Video-ingangssignalen
2x DisplayPort 1.2
USB-poorten
1x USB 2.0 upstream (endpoint)
2x USB 2.0 downstream
Nominaal vermogen
100-240 Vac, 50/60 Hz, 3.6-1.6 A
Stroomverbruik
75 W (nominal) @ calibrated luminance of 450 cd/m²
< 0.5 W (hibernate)
< 0.5 W (standby)
Afmetingen met standaard (B x H x D)
651 x 482~582 x 238 mm
Afmetingen zonder standaard (B x H x D)
651 x 390 x 66 mm
Afmetingen verpakt (B x H x D)
800 x 650 x 295 mm
Nettogewicht met standaard
12.5 kg
Nettogewicht zonder standaard
7.9 kg
Netto gewicht verpakt
17.4 kg (without optional accessories)
Kanteling
-5° to +25°
Zwenking
-30° to +30°
Scharnieren
N/A
Hoogteregelbereik
100 mm
Montagestandaard
VESA (100 mm)
Aanbevolen modaliteiten
Digital Pathology and Whole Slide Imaging
Certificeringen
FDA 510(k) K203364
CE (In Vitro Diagnostic Medical Device)
CCC (China)
Safety specific:
EC 60950-1:2005+A1:2009+A2:2013
EN 60950-1:2006+A1:2010+A11:2009+A12:2011+A2:2013
IEC 62368-1:2018
EN IEC 62368-1:2020+A11:2020
IEC 60601-1:2005+A1:2012+A2:2020
EN 60601-1:2006+A1:2013+A12:2014+A2:2021
AAMI ES 60601-1:2005+A1:2012+A2:2021
CAN/CSA C22.2 No. 60601-1:2014 (Reaffirmed 2022)
IEC 61010-1:2010+A1:2016
EN 61010-1:2010+A1:2019 (Ed. 3.1)
UL 61010-1:2012+R1:2019+R2:2023 (Ed. 3.2)
CAN/CSA C22.2 No. 61010-1:2012+A1:2018 (Ed 3.1) (Reaffirmed 2023)
EMI specific:
IEC 60601-1-2:2014+A1:2020 (Ed.4.1)
EN 60601-1-2:2015+A1:2021 (Ed.4.1)
IEC 61326-2-6:2020 (Ed. 3.0)
EN IEC 61326-2-6:2021
FCC part 15 Class B
ICES-001 Level B
VCCI (Japan)
RCM (Australia)
Environmental:
EU RoHS, China RoHS, REACH, Canada Health, WEEE, Packaging Directive
Meegeleverde accessoires
User guide
Documentation disc
Video cables
Mains cables
USB cable
Touch pad
Optionele accessoires
MXRT display controller
QA-software
QAWeb Enterprise
Garantie
5 years, including 20000 hrs backlight warranty
Temperatuur tijdens gebruik
0 °C to 35 °C (20 °C to 30 °C within specs)
Opslagtemperatuur
-20 °C to 60 °C
Luchtvochtigheid tijdens gebruik
8% to 80% (non-condensing)
Luchtvochtigheid bij opslag
5% to 85% (non-condensing)
Werkdruk
50 kPa minimum
Opslagdruk
50 to 106 kPa
