NGS‑D320 FLEX

Uitschrijven voor dit product

Compact 4K single channel H.264 & V2D Encoder

NGS‑D320 FLEX

Uitschrijven voor dit product

Compact 4K single channel H.264 & V2D Encoder

Superb Visual Experience
Simple Integration
No Adjustment Needed
Performance
Flexible switching between the H264 or V2D protocol
Part of the TFN and OpSpace Product families

The NGS-D320 FLEX is a versatile and powerful networked H.264 and V2D encoder. Its elegant design, small form factor and silent operation allows the device to be used in any situation, both in office environments and in 24/7 mission critical applications.

Due to its versatility, the NGS-D320 FLEX can be configured at runtime as an encoder, both for DVI, HDMI and DisplayPort content, with or without audio and USB KB/M. Unique in the market, it supports 2 types of streaming protocols (H264 and V2D) in a flexible way, enabling the best possible user experience for a wide variety of use-cases. The combination of these functions, with integrated keyboard and mouse control in a single unit, is ideal to create a seamless environment for application sharing, simulation and training.

Key features:

Superb Visual Experience
The NGS-D320 FLEX comes with Barco’s latest image processing engine, which provides the best scaling and color space conversion algorithms on the market today. When distributing graphics, the encoder preserves even the smallest details, making it suitable to encode images like spreadsheets or single pixel line diagrams.
Simple Integration
The device automatically starts streaming whenever a valid input signal is connected. The stream is automatically set up using the most optimal settings based on input resolution and bandwidth. In addition, the discovery page of the web interface gives an overview of all available devices in the network, making system configuration easy. The device is validated to work in Barco Transform N 3.3 or higher and OpSpace 1.4 or higher.
No Adjustment Needed
With automatic EDID management, the best experience in distributing graphics and video over IP is guaranteed.
Performance
The NGS-D320 FLEX comes with a dual link DVI, an HDMI 1.4 and a DisplayPort 1.1a input. All inputs support resolutions up to 4096 x 2160 (DCI) and feature active pass-through connectivity. Encoding in full frame rate or lower frame rates are possible, allowing you to define the quality/bandwidth balance. The encoder latency is below 40ms enabling the foundation for a low end-to-end latency in a broad variety of systems.

Specificaties

Download specificatieblad

Number of inputs and outputs

Audio: 1 3.5mm jack stereo line level in & line out
1 3.5mm jack mono mic in & stereo headphones out (combined)

USB: 3 Type A connectors, 1 Micro-B connector

Netwerk: RJ45 (1Gb copper)

Video: 1 Dual Link DVI & 1 DisplayPort 1.1a & 1 HDMI 1.4 input
1 Dual Link DVI & 1 DisplayPort 1.2 & 1 HDMI 1.4 output
Flexible Loop Through
Maximum input bandwidth of 330Mhz

Network interfaces

Ethernet: 2x 1GbE full duplex

IP-adressering: DHCP, link local, fixed IP

Protocollen: Unicast, Multicast (IGMP v3), RTP, RTSP, DNS, NTP

RTSP-sessies: Multicast: maximum 12 simultaneous RTSP session per channel
Unicast : maximum 2 simultaneous RTSP session per channel

Detectie: Zeroconf, SAP (RFC 2974)

Management interfaces

Firmware-upgrade: HTTPS Web interface, USB Storage Device

Alleenstaand: HTTPS Web interface

Advanced features

Beeldverwerking: Color space conversion, scaling, frame rate reduction

Automatische verkleining: Y (Adjust to profile)

Extern toetsenbord en muis: Supported (Native keymap)

General specifications

Afmetingen: 38 mm H x 170 mm W x 170 mm D | 1.5” H x 6.7” W x 6.7” (+/- 2mm / 0.1”)

Gewicht: 1 ± 0.01 kg (2.20 lbs)

Vermogen: Typical 35W, maximum 48W

Voeding: 12VDC, 100-240VAC 60W, external locking power

Bedrijfstemperatuur: 0°C to 40°C (32°F to 104°F)

Opslagtemperatuur: -20°C to 70°C (-4°F to 158°F)

Geluidsniveau: Typical 32dBA at 20°C

Montage: Optional VESA adapter plate or 1U rack mount for 2 devices

Certification

EMC: CE, FCC Part 15 Class A, ICES003

Veiligheid: UL/ cUL/ EN/ IEC 60950-1 CB report

Wettelijke naam: NGS-D320

Packaging characteristics

Afmetingen (verpakt): 382mmx273mmx85mm | 15,04"x10,75"x3,35"

Gewicht (verpakt): 2.2 kg | 4.8 lbs

NGS-D320 Flex

Aantal kanalen: 1

Aantal streams: 1

Grafisch: 640x480 - 2560x1600 24-60Hz
640x480 - 4096x2160 24-30Hz

Audio: 16bit 48kHz stereo

Codec: Video: H.264 up to level 5.0 or V2D
- 60fps: up to 1920x1200 (1x)
- 30fps: up to 2560x1600 (1x)
- 15fps: up to 4096x2160 (1x)

Bandbreedte: Video:
H.264 384kbps – 12 Mbps
V2D 25Mbps – 100Mbps
Audio: uncompressed

Latentie encoder-decoder end-to-end: 80-200ms (typical 100ms)

Opstarttijd: 15s
