ClickShare Hub Pro and Sennheiser TeamConnect Bar M bundle for Teams Rooms

Wireless presentation: 4K content sharing with 2 next-gen ClickShare Buttons with USB-C DisplayPort™
Wireless BYOD for Microsoft Teams Rooms to run other videoconferencing platforms (Zoom, WebEx, Google Meet, etc.)
Built on the Microsoft Device Ecosystem platform (MDEP)
Dual display support
4K Ultra HD camera with advanced AI features
Premium-quality audio with 6 microphones and 4 speakers

Free trial

Price

List price:

(excl. VAT, duties and freight)

Price not available

Resources & tools

Download spec sheet

Download App

ClickShare warranty & support

XMS Cloud Management Platform

Firmware updates

Find compatible AV technology

Download spec sheet Manuals, drivers and support

The ClickShare Hub Pro and Sennheiser TeamConnect Bar M bundle is a certified Microsoft Teams Rooms solution for medium meeting rooms. It offers effortless wireless conferencing, 4K sharing, dual screen support, and advanced audio and video. Participants enjoy enhanced collaboration, while IT benefits from security, compliance, and standardized integration.

Next-gen ClickShare Button

The ClickShare Button 5th gen, featuring Wi-Fi 6E, offers faster speeds and more reliable connectivity for smooth, uninterrupted collaboration.

Featuring USB-C DisplayPort™, it enables guest-friendly, plug-and-play sharing — no software or drivers needed.

For added privacy and control, the ClickShare Button requires a deliberate press, preventing accidental sharing.

Works seamlessly across all major OS in high-security environments
Built-in security and user control

Specifications

Download spec sheet

General Specifications

Operating system: Android (MDEP)

Microsoft Teams Rooms license required: Yes

System requirements: For ClickShare App. Minimum: Intel Core i3 or AMD Ryzen 5, 8GB RAM, Windows 10 20HS; Intel Core i3 or Apple Silicon M1, 8GB RAM, macOS 11 Big Sur Recommended: Intel Core i5/Ultra 5 or AMD Ryzen 7, 8GB RAM, Windows 11 latest build; Apple Silicon M3, 8GB RAM, macOS latest build

Video outputs: HDMI-1: UW5K WUHD (5120*2160) @30Hz HDMI 2.0 HDMI-2: 4K UHD (3840*2160) @30Hz HDMI 2.0 eDP (Control Panel): HD (1280*800) @60Hz DP 1.4

Video inputs: 4K UHD (3840*2160) @30Hz HDMI 2.0

Camera: Sennheiser TeamConnect Bar S

Camera AI: Person tiling and autoframing

Audio output: USB-A 2.0/3.0 USB-C 2.0/3.0 HDMI 2.0

ClickShare Buttons: 2 ClickShare Buttons 5th Generation

Microphones: 4 Sennheiser beamforming microphones with the option to add extension mics

ClickShare App: Desktop

Speakers: 2 Sennheiser speakers

Maximum sources simultaneously on screen: 1

Noise Level: Maximum 25 dBA @ <30°C Maximum 30 dBA @ >30°C

Wireless transmission protocol: IEEE 802.11 a/b/g/n/ac/ax/be and IEEE 802.15.1 BT 5.3

Reach: Max. 30m (100ft) between ClickShare Button and ClickShare Base Unit

Frequency band: 2.4GHZ, 5GHz and 6GHz DBS/HBS (DFS channels supported in select number of countries)

Connections: Back: 1x Ethernet LAN 1Gbit 1x USB-C Power delivery 3.1 EPR (for power adapter) 2x HDMI 2.0 output 2x USB-C 2.0/3.0 1x USB-A 2.0/3.0 1x USB-C 2.0/3.0 Device + USB-C DisplayPort™ output 1x USB-C 2.0 + USB-C DisplayPort™ output Front: 1x USB-C 2.0/3.0

Temperature range: Operating: 0°C + 40°C (+32°F to +104°F) Max 35°C (95°F) at 3000m Storage: -20°C to +60°C (-4°F to + 140°F)

Humidity: Storage: 0 to 90% relative humidity, non-condensing Operation: 0 to 85% relative humidity, non-condensing

Anti-theft system: Kensington lock

Certifications: FCC/CE

Network connection: LAN

Management and reporting: Yes, XMS Cloud

Warranty: 3 years standard

Dimensions (HxWxD): 37 * 180 * 180 (mm)

Power consumption: Operational: 160W (max) Standby: <7W (ECO mode), <0.5W (Deep Sleep mode)

Power supply: External USB-C charger 100W (PD3.0 SPR), 180W (PD3.1 EPR)

Weight: 720gr

ClickShare 10M 20W USB-C AOC Cable (Directional)

Cable Length / Diameter: A0M / 6mm

Interface: USB Type-C 3.2 Gen1, DP 1.4

Power Delivery: 20W

Bend Radius: 60mm/30mm (Fixed/Temporarily) While a minimum bend of 30mm is acceptable during handling or routing, it must not be maintained as a permanent fixture

Temperature range: Operating: -10°C + 60°C (+14°F to +140°F) Storage: -20°C to +70°C (-4°F to + 158°F)

Humidity: Storage/Operation: 0 to 85% relative humidity, non-condensing

Flame rated: VW-1 (Not plenum reated)

Power supply

AC Input: 100-240V~50-60Hz 1.4A

DC Output: 100W max (20V 5A) / 45W (15V 3A) / 36W (12V 3A) / 27W (9V 3A) / 15W (5V 3A)

Output Plug: USB Type-C

Input AC Type: IEC60320-C6

Energy Efficiency Level: Comply with DOE standard Level VI

Altitude: 5,000 meters

DC cable length: 1.5m

Power cord

Color: Black

Length: 0.5m

Plug Type: EU / US / UK / CN / CH / IN / ZA / ANZ

Connector Type: IEC60320-C5

Control Panel

Touchscreen: 10.1-inch projected capacitive touchscreen with anti-fingerprint and anti-glare coatings, supporting up to 4 touch points for enhanced visibility and durability

Resolution: 1280*800 @60Hz

Brightness: 300 nits

Contrast ratio: 1000:1

Viewing angle: 80° (Up/Down/Left/Right)

Human detection sensor: Automatically detects in-room human movement within a 2-meter range and 90° field of view to wake the system.

Connections: USB Type-C 2.0, DisplayPort Alt Mode, PD3.0 Recommend using the included ClickShare 10M USB-C AOC cable for optimal performance

Anti-theft system: Kensington lock

Temperature range: Operating: 0°C + 40°C (+32°F to +104°F) Storage: -20°C to +60°C (-4°F to + 140°F)

Humidity: Storage: 0 to 90% relative humidity, non-condensing Operation: 0 to 85% relative humidity, non-condensing

Dimensions (HxWxD): 254.5 x 187.9 x 76.9 (mm)

Power consumption: Powered over USB from connected Base Unit Operational: 7.3W (max) Standby: <0.5W

Effortless meetings and enhanced collaboration

ClickShare Hub Pro is a premium modular video conferencing system for enhanced hybrid meetings. For meeting participants, it offers:

Ease of use with no training required. Plug in, press and share!
Wireless presentation of 4K content with two ClickShare Button 5th gen
The flexibility to share from anywhere in the room
Dual and ultrawide screen support for highly visual, engaging meetings

A sound investment for IT managers

ClickShare Hub Pro is a sound investment for decision-makers looking to equip their workplace with a future-proof solution:

Native Microsoft Teams Rooms for easy integration with company systems
Secure by design, cloud-managed, and built on the Microsoft Device Ecosystem platform (MDEP)
Flexible, customizable system for all room types – ideal for both ad hoc and scheduled meetings

One-tap control with the ClickShare Control Panel

The ClickShare Control Panel is a key component of the ClickShare Hub Core or Hub Pro systems. It offers intuitive, one-tap control and smooth integration with your Microsoft Teams Room setup.

Whether you choose the modular flexibility of ClickShare Hub Core or the dual-display power of ClickShare Hub Pro, the Control Panel completes the experience — bringing simplicity, speed, and elegance to every hybrid meeting.

accessories

ClickShare 2-in-1 Tray R9861700T01 ClickShare Power Cord B1960156K ClickShare Power Supply 100W B563235K ClickShare Power Supply 180W ClickShare USB-C Input converter R9861581 ClickShare wall mount plate B570170K
