Nio Color 8MP (MDNC‑8132) MKII
Your perfect fit for radiology diagnostic reading and clinical collaboration at home, in the hospital, anywhere
- 32” display with 8MP resolution
- Integrated multimedia functionalities and built-in LAN connector slot
- Automated, remote QA and compliance
- KVM to seamlessly connect multiple workstations
- USB-C connectivity for data, multimedia, internet and power transfer
- Display Partitioner: split 1 input source into 2 halves on your screen
Looks like you haven't accepted cookies
Activate performance cookies to watch this video.
Barco's Nio Color 8MP display is the ideal choice for radiology image interpretation in various settings. It seamlessly merges our acclaimed image quality and detail with built-in features that make collaboration with peers – from any location – easy and clutter-free.
Excellent 8MP image quality on a large 32” screen
Whether you're working in an office, at home, or any other location, a solid setup is crucial. With its remarkable 8MP resolution and generous 32” screen, Nio Color 8MP empowers you to combine the information and images you need on a single screen.
The monitor includes our Intuitive Workflow Tools and cutting-edge technologies:
- SteadyGray for precise and consistent representation of grays
- SteadyColor for accurate and consistent representation of colors
- I-Guard for stable performance across the display’s full lifetime
- Uniform Luminance Technology for screen-wide uniformity correction
- Ambient Light Compensation for optimal viewing in various lighting conditions
- RapidFrame for sharp and fast image rendering when scrolling through cine images
Your perfect fit for reading radiology images, anywhere
In addition to the Nio Color 8MP’s exceptional core features, you also get:
- Integrated camera, speaker, microphone, and LAN port
- Our advanced screensharing tool Multi-Display Confer, for smooth virtual collaboration
- KVM functionality for effortless switching between multiple workstations including picture-by-picture
- USB-C port for flexible connectivity with laptops and mobile devices
- Daisy chaining to keep your desk free of cable clutter
Stable performance, remotely managed
Enjoy automated QA and compliance for a stable performance anywhere, during the full lifetime of your display, thanks to QAWeb Enterprise. Finally, Barco’s all-inclusive warranty assures you a full return on investment over at least 5 to 7 years of your display.
Ensuring diagnostic confidence with MDR Class IIa
Our radiology displays are CE marked as Class IIa in accordance with Regulation (EU) 2017/745 (MDR). Their product information has been reviewed and cleared by independent medical and technical experts, and is audited yearly. In other words, we ensure diagnostic confidence and peace of mind for our users.
A+ ecolabel for Nio Color 8MP
The Nio Color 8MP has been subjected to Barco’s ecoscoring protocol and has received an A+ rating. Some key factors that contributed to this rating are:
- Automatic standby mode when device is not in use
- Use of plastics containing 35% post-consumer recycled content
- >50% halogen-free cables & >65% halogen-free PCBs
- >90% recyclable packaging
- 5 years all-inclusive warranty, extendable to 7 years
Specifications
Download spec sheetGeneral Specifications
- Screen technology
- IPS
- Active screen size (diagonal)
- 812.80 mm (32.0")
- Active screen size (H x V)
- 708.48 x 398.52 mm (27.9 x 15.7")
- Aspect ratio (H:V)
- 16:9
- Resolution
- Native 8MP (3840 x 2160 pixels @ 60 Hz)
Configurable to 2x 4MP+ (1920 x 2160 pixels @ 60 Hz)
- Pixel pitch
- 0.1845 mm
- Color imaging
- Yes
- Gray imaging
- Yes
- Bit depth
- 30 bit
- Viewing angle (H, V)
- 178°
- Uniformity correction
- ULT
- SteadyGray
- Yes
- SteadyColor
- Yes, (in MXRT Display Controller), when used as a system with MXRT Display Controller & QAWeb Enterprise )
- Pathology Setting
- Yes
- Color gamut NTSC
- NTSC: 94%
- Color gamut sRGB
- sRGB: 132%
- sRGB Delta E2000 (typical)
- Average : < 3
Max: < 5
- Ambient light presets
- Yes, reading room selection
- Ambient light sensor
- Yes
- Front sensor
- Yes, I-Guard
- Presence sensor
- Yes
- Maximum luminance (panel typical)
- 850 cd/m²
- DICOM calibrated luminance
- 500 cd/m²
- Contrast ratio (panel typical)
- 1350:1
- Response time ((Tr + Tf)/2) (typical)
- 12.7 ms
- Housing color
- Black (RAL 9004) / White (RAL 9003)
- Video input signals
- 2x DisplayPort 1.4
1x USB-C 3.2 DisplayPort Alt Mode
- Video output signals
- 1x DisplayPort 1.4 (MST)
- USB ports
- Upstream:
2x USB-B 2.0
1x USB-C 3.2 (DisplayPort Alt Mode, Power Delivery up to 75W)
Downstream:
2x USB-A 2.0
1x USB-A 2.0 (side of the display)
1x USB-C 2.0 (side of the display, Power Delivery up to 7.5W)
- LAN/RJ45 ports
- 1x 1GbE
- Power rating
- DC input: 24VDC 8.3A
USB-C output: 5VDC 3A, 9VDC 5A, 15VDC 5A, 20V 3.75A
USB-C output (side): 5VDC 1.5A
- Power requirements
- This device shall only be powered by the medical approved power supply of Adapter Tech., type ATM200T-P240:
Input: 100-240VAC, 50-60Hz, 2.5-0.9A
Output: 24VDC, 8.3A
- Power consumption
- 65 W (nominal)
< 0.35 W (hibernate)
< 0.30 W (switched off)
- Dimensions with stand (W x H x D)
- 743 x 518~618 x 238 mm
- Dimensions w/o stand (W x H x D)
- 743 x 459 x 63 mm
- Dimensions packaged (W x H x D)
- 898 x 752 x 358 mm
- Net weight with stand
- 13 kg
- Net weight w/o stand
- 8.4 kg
- Net weight packaged
- 21 kg (without optional accessories)
- Tilt
- -5° to +25°
- Swivel
- -30° to +30°
- Pivot
- N/A
- Height adjustment range
- 100 mm
- Mounting standard
- VESA (100 mm)
- Screen protection
- N/A
- Recommended modalities
- All digital images, except digital mammography.
- Certifications
- CE0123 (Medical Device)
FDA 510(k) K233693
CCC (China) (pending), KC (Korea) (pending), INMETRO (Brazil) (pending), BIS (India) (pending), EAC (Russia) (pending)
Safety specific:
IEC 62368-1:2018
EN IEC 62368-1:2020+A11:2020
IEC 60601-1:2005+A1:2012+A2:2020
EN 60601-1:2006+A1:2013+A2:2021
AAMI ES 60601-1:2005+A1:2012+A2:2021
CAN/CSA C22.2 No. 60601-1:2014 (Reaffirmed 2022)
EMI specific:
IEC 60601-1-2:2014+A1:2020 (Ed.4.1)
EN 60601-1-2:2015 + A1:2021 (Ed.4.1)
FCC part 15 Class B
ICES-001 Level B
VCCI (Japan) (pending)
Environmental:
EU RoHS, China RoHS, REACH, Canada Health, WEEE, Packaging Directive
- Supplied accessories
- User Guide
Quick Install Sheet
Documentation disc
System sheet
Video cables
Mains cables
USB cable
External power supply
- Optional accessories
- Display controller
Touch pad
- QA software
- QAWeb Enterprise
- Warranty
- 5 years, including 20000 hours backlight warranty
- Operating temperature
- 0 °C to 35 °C (20 °C to 30 °C within specs)
- Storage temperature
- -20 °C to +60 °C
- Operating humidity
- 8 % to 70 % (non-condensing)
- Storage humidity
- 5 % to 70 % (non-condensing)
- Operating pressure
- 70 kPa
- Storage pressure
- 50 to 106 kPa
