TruePix TP1.9

TruePix TP1.9

1.9 mm pixel pitch, high-res indoor LED display

TruePix TP1.9

1.9 mm pixel pitch, high-res indoor LED display

  • Smart engineering guarantees truly seamless outcomes
  • Smooth and efficient operations, 24/7
  • Superb color accuracy, under all lighting conditions
  • Reduced ecological footprint
  • Up to 10 years of dedicated service and support

R9408550

TruePix TP1.9 TILE

R9408551

TruePix TP1.9 TILE Redundant PSU

R9408552

TruePix TP1.9 TILE Curved

R9408553

TruePix TP1.9 TILE Redundant PSU Curved

TruePix TP1.9 is Barco’s new flagship indoor high-resolution LED platform. The 27.5” inch tiles, with a 16:9 aspect ratio, have a pixel pitch of 1.9 mm. TruePix is designed for control room, corporate and broadcast visualization applications and supports both environments exposed to ambient light and controlled lighting environments.

Truly seamless outcomes

TruePix sets a new standard for the LED video wall experience based on decades of experience. The solution brings content to life as intended and ensures predictable, truly seamless outcomes, by combining smart engineering and Infinipix® Gen2, the next generation of Infinipix®. Smooth and efficient operations are guaranteed 24/7, next to full peace of mind.

Barco TruePix’ smart engineering introduces a unique mechanical concept for risk-free and precise installations, eliminating visual distortion. This unmatched seamlessness and flatness are achieved through guided module placement and self-leveling mounts. The next generation of Barco’s proprietary Infinipix® processing – Infinipix® Gen2 – guarantees full image integrity at any brightness level, together with superb color accuracy. It flexibly and automatically supports any content need while reducing eye fatigue.

Peace of mind at any time

Smooth and efficient operations are guaranteed 24/7 through uninterrupted data flows. Users can reduce the carbon footprint by using the EcoPower standby mode. Up to 10 years of dedicated service and support (ensuring a uniform viewing experience) and remote cloud-based video wall management, allow for peace of mind during the entire product lifetime.

Specifications

Download spec sheet
General specifications
Pixel pitch
1.906
Pixel per tile
320x180 (HxV)
LED lifetime
100,000h (video - 50% brightness)
Brightness
>800 nit
Internal processing
23 bit
Color depth
16 bit (281 trillion colors)
Shaders
Yes
Control
Infinpix® Gen2
Refresh rate
3,840 Hz
Frame rate
24 / 25 / 29.97 / 30 / 47.95 / 48 / 50 / 59.94 / 60 / 100 / 119.88 / 120 / 144 / 240 Hz
3D
3D supported
Hor. viewing angle
160° +/-5°
Vert. viewing angle
160° +/-5°
Brightness uniformity
>98%
Dimming
0-100%
Contrast
>11,000:1
Power consumption
646 W/m² 136 W/Tile (max)
215.3 W/m² 45 W/Tile (typ)
<10 W/m² (standby)
Heat dissipation
2,202 BTU/h/m² (max)
734 BTU/h/m² (typ)
Heat dissipation front/back
54%/46%
Operation power voltage
AC power:
    100-240 V 50/60 Hz
DC power:
    Input: 36-55Vdc 16A (max.)
    Output: 36-55Vdc 10.72A/36V (max.) or 12.55A/55V (max.)
Operational temperature
-10°C to +40°C / 14°F to 104°F
For ceiling mounted installations: max temp +30°C/86°F
Operational humidity
10 - 80%
IP rating
IPx0
Redundancy
Power: Optional
Data: Inter-tile and signal loop redundancy embedded / N + N redundancy optional
HDR
HLG / HDR10 supported
Concave curvature
Up to 5° inter tile for standard and camera curved frame (7m radius)
Up to 5° inner tile for standard and camera curved frame (3,5m radius)
Convex curvature
Up to 3° inter tile for standard curved frame (12m radius)
Convex curving is not applicable for camera curved frame
Dimensions
(WxHxD) 609.92x343.08x71mm / 24.01"x13.5"x2.80"
Weight
7.5kg/tile (single PSU) 8 kg/tile (dual PSU)
Serviceability
Full front & full back service
Cable management
No external cabling
Installation
Self-leveling with surface tolerance compensation
Module replacement
Automated parallel motorized extraction
Module placement
Guided module placement
Ergonomics
SteadyView™ driver algorithm to reduce eye fatigue
Certifications
CE, UL, FCC class A, RoHS, WEEE, REACH, CCC, RCM
TAA Compliancy
Not available
Warranty
3 years
SmartCare / EssentialCare service offering
10 years
