    ClickShare CX-30
    Get your quote

    ClickShare CX‑30

    Seamless wireless conferencing for small to medium-sized meeting and conference rooms

    Barco green product

    ClickShare CX‑30

    Seamless wireless conferencing for small to medium-sized meeting and conference rooms

    • Interactive features: touchback, annotation and blackboarding
    • Increased collaboration with 2 sources on screen
    • Run video meetings from your laptop with Button or App
    • 100% secure, encrypted and cloud-managed
    Get your quote Where to buy
    1. Download specsheet
    2. Product finder
    3. ClickShare ROI Calculator
    4. XMS Cloud Management Platform
    5. Get product support

    R9861513CN

    ClickShare CX-30 - CN version

    R9861613CNB2

    ClickShare CX-30 Gen2 - Chinese version with 2 Buttons

    R9861513EU

    ClickShare CX-30 - EU version

    R9861613EUB2

    ClickShare CX-30 Gen2 - EU version with 2 Buttons

    R9861513NA

    ClickShare CX-30 - NA version

    R9861613NAB2

    ClickShare CX-30 Gen2 - NA version with 2 Buttons

    R9861513RW

    ClickShare CX-30 - RW version

    R9861613RWB2

    ClickShare CX-30 Gen2 - RW version with 2 Buttons

    R9861513US

    ClickShare CX-30 - US version

    R9861613USB2

    ClickShare CX-30 Gen2 - US version with 2 Buttons

    R9861513ZH

    ClickShare CX-30 - ZH version

    R9861613ZHB2

    ClickShare CX-30 Gen2 - ZH version with 2 Buttons



    ClickShare CX-30 enables wireless conferencing in medium-sized meeting spaces. When you walk into the meeting room, ClickShare automatically connects you to room devices like cameras, mics, speakers, sound bars and displays.

    Start a meeting from your laptop within seconds, using your preferred video conferencing platform. Make hybrid meetings easy, with just one click on the ClickShare Button or the ClickShare App, both for employees and guests.

    Specifications

    Download spec sheet
    ClickShare Base Unit dimensions
    Dimensions (HxWxD)
    34 mm x 135 mm x 135 mm
    Power supply
    Standard 110/220 V AC plug or USB-C (only Gen2)
    Power consumption
    Operational: 5-10W, 24W Max
    Weight
    900 gr
    General specifications
    Operating system
    Windows 10 and higher macOS 11 (BigSur) and higher
    Android v11 and higher (ClickShare App)
    iOS 14 and higher (ClickShare App)
    System requirements
    For a smooth experience with Microsoft Teams or Zoom
    Minimum: Intel i3 dual-core processor / 8GB RAM / OS: Windows 10 latest build or Mojave latest build
    Recommended: Intel i5 4-core processor / 8GB RAM / OS:Windows 10 latest build or Mac OS latest build
    Video outputs
    4K UHD (3840*2160) @ 30Hz. HDMI 1.4b or USB-C DisplayPort 1.2 (only Gen2)
    Audio output
    USB, HDMI
    USB
    1 X USB-A, 1 X USB-C
    ClickShare Buttons
    2
    ClickShare App
    Desktop & Mobile
    Native protocols

    Airplay, Google Cast, Miracast

    Maximum number of simultaneous connections (with Buttons and/or App)
    32
    Noise Level
    Max. 25dBA @ 0-30°C
    Max. 30dBA @ 30-40°C
    Authentication protocol
    WPA2-PSK in stand alone mode
    WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode
    Wireless transmission protocol
    IEEE 802.11 a/g/n/ac and IEEE 802.15.1
    Reach
    Max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit
    Frequency band 2.4 GHZ and 5 GHz (DFS)
    Frequency band
    2.4 GHZ and 5 GHz (DFS channels supported in select number of countries)
    Connections
    1x Ethernet LAN 1Gbit
    1x USB-C 2.0 (front); 1x USB-A 2.0 (front) - only Gen2: 1x USB-C 3.0 (front); 1x USB-A 3.0 (front)
    Temperature range
    Operating: 0°C to +40°C (+32°F to +104°F)
    Max: 35°C (95°F) at 3000m
    Storage: -20°C to +60°C (-4°F to +140°F)
    Humidity
    Storage: 0 to 90% relative humidity, non-condensing
    Operation: 0 to 85% relative humidity, non-condensing
    Anti-theft system
    Kensington lock
    Certifications
    FCC/CE
    Touch screen support & Interactivity
    Yes
    Wireless conferencing
    via App or Button
    Local view
    Yes
    Network connection
    LAN & WiFi
    Management and reporting
    Yes
    Warranty
    1 year standard. 5 years coverage via SmartCare
