F80-4K7

F80‑4K7

7,000 lumens, 4K UHD, DLP laser phosphor projector

F80‑4K7

7,000 lumens, 4K UHD, DLP laser phosphor projector

  • Stunning images with superb color performance
  • Ultimate installation flexibility
  • 3D capable
  • Silent operation

The stunning image quality and laser phosphor light source of Barco's F80 projectors enable you to provide exceptional experiences while saving both time and money. They're designed for fixed installation in a wide range of applications such as museums, board rooms, and auditoriums. Thanks to their 3D capability, they're also perfectly fit for theme park dark rides and interactive experiences.

Superior image quality

The F80-4K7 delivers stunning images with highly saturated colors that allow for accurate color reproduction at all times. What's more it features the powerful Barco Pulse processing that allows for sharper images and less latency thanks to its Single Step Processing (SSP).

Unprecedented business value

With this projector you can increase your uptime while driving costs down. Through its laser-phosphor light source and advanced cooling design, it provides a long operating time without need for lamp changes - resulting in considerable cost-savings on maintenance and consumables.

Ultimate installation flexibility

The F80-4K7 gives you more flexibility in projector location and orientation as it can run in any orientation. Thanks to its wide array of all-glass lenses and wide lens shift ranges, the F80-4K7 accommodates almost any projector configuration.

Specifications

Download spec sheet
General specifications
Projector type
Single-chip DLP (0.67") laser phosphor projector
Resolution
3,840 x 2,400 (4K UHD) / 2,716 x 1,600 (WQXGA+ native)
Brightness

7,000 center lumen*

6,600 ansi lumen

7,500 ISO lumen

Brightness uniformity
> 90%
Contrast ratio
1,200:1 sequential, 10,000:1 dynamic *
Light source
Laser phosphor
Light source lifetime
> 20000 h in normal mode, > 12000 h in silent mode, > 40000 h in long life mode, > 12000 h in high brightness mode
Aspect ratio
16:10
Color space
Rec. 709
Orientation
360° rotation, no restrictions
Sealed DLP™ core
Yes
24/7 operation
Yes**
Color correction
P7 RealColor™
CLO (constant light output)
Yes
Keystone correction
Yes
Image processing
Embedded warp & blend engine
3D
Active stereoscopic 3D / Passive stereo compatible
Lens type
GLD/FLDX/FLD+(lens adapter needed)
Optical lens shift
Vertical up to 125%, depending on lens
Horizontal up to 50%, depending on lens
Motorized zoom and focus (with lens memory on GLD and FLDX lenses)
Motorized lens shift (with position memory on all lenses)
Inputs

12G-SDI, 2x DP 1.2, 2x dual link DVI-D, HDBaseT, HDMI2.0 (HDCP2.2, HDR10), RJ 45 Ethernet, DMX in/out, RS232 in, 2x USB, 12V out

Input resolutions

Up to 4K UHD @ 60Hz / Up to 2,560 x 1,600 @ 120Hz

refresh rates:

24Hz to 120Hz for WQXGA+ (2716x1600) and 24Hz to 60Hz for 4K/4KUHD (4096 x 2160/ 3860 x 2400)

Software tools
Projector Toolset
Control
IR, RS232, RJ45, XLR wired
Network connection
10/100 Ethernet, RJ45
Power requirements
100-240V / 50-60Hz
Power consumption
700 W nominal, 850 W maximum
Standby power
<0.5W
BTU per hour
2,400 BTU/h nominal, 2,900 BTU/h maximum
Noise level (typical at 25°C/77°F)
35 dB(A)
Operating temperature
10°C (50°F)- 40°C (104°F) (up to 1500m altitude) / 10° (50°F) - 35°C (95°F) (up to 3000m altitude)
Operating humidity
20 - 80% RH (non-condensed)
Storage - transport temperature
-20 to 60 °C
Storage humidity
20 - 90% RH (non-condensed)
Dimensions (WxLxH)
480 x 680 x 227 mm / 18.9 x 26.7 x 8.9 in
Weight
25.5 kg / 56.2 lbs
Standard accessories
Power cord, wireless remote control
Certifications
CE, FCC Class A, cNemkoUS, CCC, EAC, KSA, RCM, UkrSEPRO
Warranty
Limited 3 years on parts and labor(***)
Extendable up to 5 years.
*
* When measured with the GLD 1.43-2.12:1 lens in Wide Angle
** For optimal performance, switch off the projector regularly. For details please consult the manual.
*** Except on light source: 20000 hours in normal mode, or 3 years, whichever comes first.
