F70‑4K6

4K UHD laser phosphor projector

F70‑4K6

4K UHD laser phosphor projector

4K UHD resolution
Durable and robust for 24/7 operation
High brightness
Long lifetime (up to 60,000 hours)

R9023463

F70-4K6

The F70-4K6 is a laser phosphor projector with native WQXGA and up to 4K UHD resolution. The F70 series answers to the simulation and ProAV market's specific requirements - including high robustness, longer lifetime, and laser-sharp image quality. Projectors that do not meet these demands don't last long or require frequent and expensive maintenance.

Fitted with protective metal, Barco’s F70 withstands a motion platform's rapid and sudden movements, making it the perfect choice for theme parks. With a lifetime of up to 60,000 hours (depending on the mode of operation), the F70 is one of the most durable projectors on the market and is ready for service in the most demanding environments.

Designed for 24/7 use

The F70 is designed for performance and reliability. Capable of running in any orientation, the F70 projectors offer more installation flexibility. All of Barco's F-series projectors feature the same high-resolution FLD and FLD+ lenses so that you can reuse your lenses.

Brighter, better

With brightness levels of 5,400 lumens, the F70-4K6 is one of the brightest single-chip DLP projectors on the market with 4K UHD resolution. With the Constant Light Output (CLO^TM) functionality, the projector produces constant brightness and color over a long period of time. And thanks to Barco’s unique and proprietary Single Step Processing (SSP^TM) technology, the F70 achieves 4K UHD resolution in only one step. So, you benefit from a sharper image and much higher overall image quality with less latency.

Specifications

Download spec sheet

General specifications

Brightness: 5,400 Typical ANSI Lumens

Contrast ratio: 1800:1 sequential, 50,000:1 dynamic

IR for NVG: no

Brightness uniformity: 90%

Aspect ratio: 16:10 native

Projector type: 1DLP laser phosphor

Resolution: 3,840 x 2,400 / 3,840 x 2,160 / 2,560 x 1,600 (native)

Lens type: FLD-series

Optical lens shift: Vertical up to 146%, depending on lens
Horizontal up to 70%, depending on lens
Motorized zoom and focus (+ lens memory FLDX lenses)
Motorized lens shift (with position memory on all lenses)

Color correction: P7 RealColor^TM

CLO (constant light output): Yes

Light source: Laser phosphor

Light source lifetime: Up to 60,000 hours, depending on mode of operation

Sealed DLP™ core: Yes

Orientation: 360° rotation, no restrictions

3D: Active stereoscopic 3D

Image processing: Embedded warp & blend engine

Keystone correction: Yes

Inputs: HDSDI
2x DP1.2
2x dual link DVI-I
HDBaseT
HDMI2.0 (HDCP2.2, HDR10)
RJ 45 Ethernet
DMX in/out
RS232 in
2x USB
12v out

Input resolutions

Including and up to:
3,840 x 2,400 @ 60Hz
3,840 x 2,160 @ 60Hz
4,096 x 2,160 @ 60Hz
2,560 x 1,600 @ 120Hz

refresh rates:

24Hz to 120Hz for WQXGA (2560x1600) and 24Hz to 60Hz for 4K/4KUHD (4096 x 2160/ 3860 x 2400)

Input color depth: DVI: Including and up to 2560x1600@60Hz 8 bit RGB and 3840x2400@50Hz 8 bit RGB
DisplayPort: Including and up to 2560x1600@120Hz 12 bit RGB and 3840x2400@60Hz 8 bit RGB

Software tools: Projector Toolset

Control: IR, RS232, RJ45

Network connection: IR, RS232, RJ45

Power requirements: 100-240V / 50-60Hz

Power consumption: 743 W nominal, 1100 W maximum

BTU per hour: Max 4,000 BTU/h

Noise level (typical at 25°C/77°F): 36 dB(A)

Operating temperature: 10 - 40 °C (sea level)

Storage temperature: -20 to 60 °C

Operating humidity: 20 - 80% RH

Storage humidity: 10 - 90% RH

Dimensions (WxLxH): 475 x 593 x 286 mm / 18,7 x 23,3 x 11,2 in

Weight: 37 kg / 81,5 lbs

Standard accessories: Power cord, wireless remote control

Certifications: CE, FCC Class A and cNus

Warranty: Limited 5 years parts and labor, extendable
