F70-W8

F70‑W8

WUXGA laser phosphor projector

F70‑W8

WUXGA laser phosphor projector

  • Durable and robust for 24/7 operation
  • High brightness
  • Long lifetime (up to 60,000 hours)

The F70-W8 laser phosphor projector answers to the ProAV market's specific requirements - including high robustness, longer lifetime, and laser-sharp image quality. Projectors that do not meet these demands don't last long or might require frequent and expensive maintenance.

Thanks to its rugged design Barco’s F70 is motion platform capable, making it the perfect choice for theme parks, dark rides and the most demanding fixed installations. With a lifetime of up to 60,000 hours (depending on the mode of operation), the F70 is one of the most durable projectors on the market and is ready for service in the most demanding environments.

Designed for 24/7 use

The F70 is designed for performance and reliability. Capable of running in any orientation, the F70 projectors offer more installation flexibility. All of Barco's F-series projectors feature the same high-resolution FLD and FLD+ lenses so that you can reuse your lenses.

Brighter, better

With brightness levels of 8,000 lumens, the F70-W8 is one of the brightest single-chip DLP projectors on the market. With the Constant Light Output (CLOTM) functionality, the projector produces constant brightness and color over a long period of time.

Specifications

Download spec sheet
General specifications
Brightness
8,000 lumens
Contrast ratio
1,800:1 sequential, 50,000:1 dynamic
IR for NVG
no
Brightness uniformity
90%
Aspect ratio
16:10
Projector type
1DLP laser phosphor
Resolution
1,920 x 1,200 (WUXGA)
Lens type
FLD/FLD+
Optical lens shift
Vertical up to 134%, depending on lens
Horizontal up to 70%, depending on lens
Motorized zoom and focus (+ lens memory FLDX lenses)
Motorized lens shift (with position memory on all lenses)
Color correction
P7 RealColorTM
CLO (constant light output)
Yes
Light source
Laser phosphor
Light source lifetime
Up to 60,000 hours, depending on mode of operation
Sealed DLP™ core
Yes
Orientation
360° rotation, no restrictions
3D
Active stereoscopic 3D
Image processing
Embedded warp & blend engine
Keystone correction
Yes
Inputs
HDSDI
2x DP1.2
2x dual link DVI-I
HDBaseT
HDMI2.0 (HDCP2.2, HDR10)
RJ 45 Ethernet
DMX in/out
RS232 in
2x USB
12v out
Input resolutions
Including and up to:
1,920 x 1200 @ 60Hz
2,560 x 1,600 @ 120Hz

refresh rates:

24Hz to 120Hz for WQXGA (2560x1600) and 24Hz to 60Hz for 4K/4KUHD (4096 x 2160/ 3860 x 2400)

Input color depth
DVI: Native including and up to 1920x1200@120Hz 8 bit RGB. Non-native including and up to 2560x1600@60Hz 8 bit RGB and 3840x2400@50Hz 8 bit RGB
DisplayPort: Native including and up to 1920x1200@120Hz 12 bit RGB. Non-native including and up to 2560x1600@120Hz 12 bit RGB and 3840x2400@60Hz 8 bit RGB
Software tools
Projector Toolset
Control
IR, RS232, RJ45
Network connection
IR, RS232, RJ45
Power requirements
100-240V / 50-60Hz
Power consumption
1,100 W Max.
BTU per hour
Max 4,000 BTU/h
Noise level (typical at 25°C/77°F)
36 dB(A)
Operating temperature
10 - 40 °C (sea level)
Storage temperature
-20 to 60 °C
Operating humidity
20 - 80% RH
Storage humidity
10 - 90% RH
Dimensions (WxLxH)
475 x 593 x 286 mm / 18,7 x 23,3 x 11,2 in
Weight
37 kg / 81,5 lbs
Standard accessories
Power cord, wireless remote control
Certifications
CE, FCC Class A and cCSAus
Warranty
Limited 5 years parts and labor, extendable
