G100‑W19

19,000 lumen, WUXGA, single-chip laser phosphor projector

Barco green product

G100‑W19

19,000 lumen, WUXGA, single-chip laser phosphor projector

single-chip high-brightness projections
up-to-date input capabilities & future-proof design
full operational flexibility through wide lens range

100% image performance

The G100 series opens up the possibilities of our single-chip offering with higher brightness levels than before. It brings great image quality with an impressive lumens power for bright projections indoor and outdoor. What's more, the G100 supports all the latest input sources, including HDMI 2.0, to assure deep color palettes and qualitative projections.

Thanks to Barco's Projector Toolset software, installing and managing your projector(s) can be done from the comfort of your own computer with the intuitive user interface. In addition, the Ptoolset blending and warping capabilities, make these projectors a perfect fit for multi-channel media-based attractions like planetariums, domes, theatres and projection mappings.

100% flexibility

To enable full operational versatility and effortless implementation in different project designs, the G100 comes with a stable lens holder to guarantee reliable blending and non-moving images in multi-channel set-ups, and a new extensive GC-lens range supporting a throw ratio going from 0.38 up to a 10.8. It gives you flexibility to shoot from long/and or short distances, and to play with 360° orientation possibilities. The projector and its peripherals deliver the best outcomes for any creative project.

With the excellent onboard cooling the G100s can withstand a maximum ambient operating temperature of 50°C (122°F), and this all only at max. 42 dB noise levels.

100% reliability

Through its laser-phosphor light source and advanced cooling design, the G100 provides a long operating time (> 20.000 hrs) without need for lamp changes - resulting in considerable cost-savings on maintenance and consumables.

With its up-to-date and future-proof design the G100 is built to meet all your requirements in terms of image quality, reliability and sustainability.

Logo_XiO_Cloud_7540_CMYK_v2

Specifications

Download spec sheet

General specifications

Projector type: Single chip DLP laser phosphor projector

Resolution: 1,920 x 1,200 (WUXGA) - 0.96" DLP chip

Brightness: 19,000 ISO lumen / 17,800 center lumen / 16,000 ANSI lumen

Contrast ratio: 1,100:1 sequential; 5,500:1 dynamic; Extreme black: 100,000:1

Brightness uniformity: 90%

Aspect ratio: 16:10

Lens type: GC-lenses - 0.65-0.75:1 / 0.84-1.02:1 / 1.02-1.36:1 / 1.2-1.5:1 / 1.5-2.0:1 / 2.0-4.0:1 / 4.0-7.2:1 / 7.2-10.8:1

Optical lens shift: Vertical up to 120%, depending on lens
Horizontal up to 50%, depending on lens
Motorized zoom and focus
Motorized lens shift

Color correction: Yes

CLO (constant light output): Yes

Light source: Laser phosphor

Light source lifetime: Up to 20,000hrs

Sealed DLP™ core: Yes

Orientation: 360° rotation, no restrictions

3D: Active and passive stereoscopic 3D

Image processing: Embedded warp & blend. Also possible via Ptoolset

Keystone correction: Yes

Inputs: 2x HDMI 2.0b / DisplayPort 1.2a / DVI-D / HDBaseT / 3G-SDI / VGA (D-Sub 15 pin)

Input resolutions

Up to 4K UHD @60Hz

Refresh rates: 24Hz to 60Hz for WUXGA and 4KUHD (4096 x 2160 / 3860 x 2160)

4K input signals will be scaled to the projector’s output resolution

Software tools: Projector Toolset*

Control: IR, RS232, RJ45, USB type A

Network connection: 10/100 Ethernet, RJ45

Power requirements: 100-240V / 50-60Hz

Power consumption: 1000W nominal, 1150W maximum (@220V)

BTU per hour: 3415 BTU/h nominal, 3925 BTU/h maximum (@220V)

Standby power: less than 0.5W

Noise level (typical at 25°C/77°F): 36dB(A) - 40dB(A) depending on the used mode

Operating temperature: 0 - 50 °C (sea level)

Storage temperature: -10 to 60 °C

Operating humidity: 10 - 85% RH, non-condensing

Storage humidity: 5 - 90% RH, non-condensing

Dimensions (WxLxH): without feet: 650 x 710 x 251 mm / 25.6 x 27.9 x 9.9 in

Weight: without lens: 50.0 kg / 110.2 lbs

Standard accessories: Power cord, wireless remote control

Certifications: CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI

Warranty: Limited 3 years parts and labor

*Note: Integration in Ptoolset in Q1/2022
