G50-W6

G50‑W6

6,000 lumens, WUXGA, DLP laser phosphor projector

  • Smallest and lightest projector in its category
  • Industry leading energy efficiency in the 5-8K lumens segment
  • Consistent image quality over time
  • Full range of interchangeable lenses (with widest lens shift)
  • Guaranteed service and support

The G50-W6 is an affordable and compact, yet powerful, single-chip WUXGA projector designed for single and multi-channel projections for boardrooms, museums, exhibitions, experience centers, and entry-level simulation applications. It is part of the economical G50 series and the Barco smart line projectors. With a great price-performance ratio, the G50s are the most compact and energy efficient projectors on the market.

The laser phosphor light source ensures great image quality, with superb colors and image uniformity. These are the smallest projectors in our offering with the highest light efficiency visualizing high-quality content at its best.

Their uniform compact size, the compatibility with Barco’s extensive G-series lenses and the wide lens shift range enlarge the projectors flexibility, which allows you to choose the perfect fit for your specific environment.

In addition, G50 owners can benefit from the valued Barco service and support. The G50 allows for an Insights Management Suite subscription, our cloud-based IoT platform to monitor, diagnose and control your projectors. And thanks to Barco's Projector Toolset software, installing and managing your projector(s) can be done from the comfort of your own computer.

Crestron Connect logo for G-series projectors
G50 wins InfoComm 2023 Best of Show award from Projector Central
Church Production logo for selecting the G50 as Top 5 InfoComm 2023 products for churches
G50 is awarded with rave pubs best of infocomm 2023 award winner for most creative new projector

Specifications

Download spec sheet
General specifications
Projector type
Single chip DLP laser phosphor projector
Technology
Single chip DLP laser phosphor projector
Resolution
1,920 x 1,200 (WUXGA)
Brightness
5,400 ANSI lumens
6,000 center lumens
6,400 ISO lumens
Brightness uniformity
90%
Contrast ratio
1,200:1 sequential;
6,000:1 dynamic;
Extreme black: 750,000:1
Light source
Laser phosphor
Light source lifetime
Up to 20,000hrs
Aspect ratio
16:10
Orientation
360° rotation, no restrictions
Sealed DLP™ core
Yes
Color correction
Yes
CLO (constant light output)
Yes
Keystone correction
Yes
Image processing
Embedded warp & blend possible via Ptoolset
3D
Active stereoscopic 3D
Lens type
G-lenses - 0.37-0.4:1 / 0.65-0.75:1 / 0.75-0.95:1 / 0.95-1.22:1 / 1.22-1.53:1 / 1.52-2.92:1 / 2.90-5.50:1
Optical lens shift
Vertical up to 100%, depending on lens
Horizontal up to 30%, depending on lens
Motorized zoom and focus
Motorized lens shift
Inputs
2 x HDMI™ In (Compliant with HDMI™ 2.0b, HDCP2.2) / 1 x Display Port (1.2a) / 1 x HDBaseT (HDCP1.4) / 1 x 3D SYNC In
Output
1 x HDMI™ Out (Loop through HDMI™1/HDMI™2/HDBaseT/DP) 1 x 3D SYNC Out 1 x DC 12V Out 1 x Audio out, 3.5mm phone jack
Input resolutions
Up to 4K @60Hz
Refresh rates: 24Hz to 60Hz for WUXGA and 4K/4KUHD (4096 x 2160 / 3840 x 2160)
4K input signals will be scaled to the projector’s output resolution
Software tools
Projector Toolset
Control
1 x RS232 (D-sub 9 pin) (PC Control)
1 x Wired In (3.5mm phone jack) (Remote In)
1 x RJ45 (LAN)
Network connection
10/100 Ethernet, RJ45
Speakers
10W / 6 Ohm *2
Power requirements
100-240V / 50-60Hz
Power consumption
300W @110V 290W @220V
Standby power
less than 0.5W
BTU per hour
1024 @110V 990 @220V
Noise level (typical at 25°C/77°F)
32dB(A) - 36dB(A) depending on the used mode
Operating temperature
0 ~ 40 °C (sea level)
Operating humidity
10 - 85% RH, non-condensing
Storage temperature
-10 ~ 60 °C
Storage humidity
5 - 90% RH, non-condensing
Dimensions (WxLxH)
without feet: 486 x 376 x 181.2mm
Weight
without lens: 11 kg / 24.25 lbs
Standard accessories
Power cord, wireless remote control
Certifications
CE, FCC Class A, cTUVUS, CCC, EAC, KCC, RCM, BIS, BSMI
Warranty
Limited 3 years parts and labor
*Note
Brightness levels +/- 10%
